Beijer Electronics - HMI Panels
GENUINE PRODUCT
QTERM operator panels
SKU: AVA-B30A3401
Category: Previous models of HMI and PCs
PRICE:
REQUEST A QUOTE
Manufacturer warranty
Overview
QTERM-N15 - AVA Air Vacuum Automation.
TECHNICAL SUPPORT & QUOTE
Talk to the AVA engineering team for the best offer.
TECHNICAL DETAILS & SPECIFICATIONS
QTERM-N15: Panel-mount HMI
|
|
The QTERM-N15 is a low-cost human machine interface terminal featuring a supertwist, 20x4 character LCD display, 12-keys, in a panel-mount configuration.
- Lighted, supertwist, 20x4, LCD display; optional vacuum-fluorescent display (VFD) - Panel-mount - -10 to 60 °C operating temperature - 12-key tactile keyboard - NEMA-12/13 sealing - 4.8 to 5.3 VDC supply without regulator; 7.5 to 24 VDC supply with optional regulator - ASCII / character-based command structure |
Facts
General description
| Part number | QTERM-Nxxx or QTERM-NxxxR |
| Life cycle status | Discontinued |
| Warranty | 1 year |
Certifications
| General | FCC, CE |
Mechanical
| Mechanical size | 109 x 151 x 35 mm |
| Housing material | Polymer |
Power
| Input voltage | 4.8 to 5.3 VDC supply without regulator; 7.5 to 24 VDC supply with optional regulator |
| Power consumption (max) | 28 mA @ 5 VDC typical (lighting off), 88 mA @ 5 VDC typical (lighting on) |
System
| RAM | 16 bytes |
Display
| Size diagonal | 20x4 |
| Backlight | Supertwist LCD, optional lighted and vacuum-fluorescent display |
Environmental
| Operating temperature | -10 to 60 °C |
| Storage temperature | -40 to 85 °C |
| Sealing front | NEMA-12/13 |
| Humidity | 0 to 95%, non-condensing |
